Description
Engine
Engine Type
Liquid-cooled, 4-stroke, SOHC, 4-valve
Displacement
155 CC
Bore & Stroke
58.0 mm ร 58.7 mm
Compression Ratio
11.6 : 1
Maximum horse power
13.5kW(18.4PS)/10000r/min
E20 Compatible
Yes
Starting system type
Electric starter
Maximum torque
14.2N.m(1.4kgf.m)/7500r/min
Fuel System
Fuel injection
Lubrication system
Wet sump
Clutch Type
Wet, Multiple Disc
Dimensions
Overall length
2005mm
Overall Width
805mm
Overall Height
1,080mm
Minimum ground clearance
170mm (At Unladen {Kerb} Vehicle Weight)
120mm (At Laden* Vehicle Weight)
Kerb Weight (with oil and full fuel tank)
137 kg
Seat height
810mm
Inner tube diameter of front fork
37.0mm
Wheelbase
1,325 mm
Fuel tank capacity
10L
Chassis
Frame type
Deltabox
Front suspension system
Telescopic upside down Front Fork
Rear suspension system
Swingarm (link suspension)
Brake type (Front)
Disc brake (282 mm)
Brake type (Rear)
Disc brake (220 mm)
Tyre size (front)
100/80-17M/C 52P – Tubeless
Tyre size (rear)
140/70R-17M/C 66H – Tubeless
ABS
Dual Channel
