Description
ENGINE
Engine Type
Liquid-cooled, 4-stroke, SOHC, 4-valve
Displacement
155 CC
Bore & Stroke
58.0 mm ร 58.7 mm
Compression Ratio
11.6 : 1
Maximum horse power
13.5kW(18.4PS)/10000r/min
E20 Compatible
Yes
Clutch Type
Wet, Multiple Disc
Transmission type
Constant mesh, 6-speed
Starting system type
Electric starter
Maximum torque
14.1N.m(1.4kgf.m)/7500r/min
Fuel System
Fuel injection
DIMENSIONS
Overall length
2015mm
Overall Width
800mm
Overall Height
1,070mm
Minimum ground clearance
170 mm
Kerb Weight (with oil and full fuel tank)
141 kg
Seat height
810mm
Inner tube diameter of front fork
37.0mm
Wheelbase
1,325 mm
Fuel tank capacity
10L
CHASSIS
Frame type
Deltabox
Front suspension system
Telescopic upside down Front Fork
Rear suspension system
Linked-Type Monocross Suspension
Brake type (Front)
Disc brake (282 mm)
Brake type (Rear)
Disc brake (220 mm)
Tyre size (front)
100/80-17M/C 52P – Tubeless
Tyre size (rear)
140/70R-17M/C 66H – Radial Tubeless
ABS
Dual Channel
OTHER INFORMATIONS
Battery
12 V, 4.0 Ah
Color TFT Meter
Equipped*
Turn By Turn Navigation
Equipped*
Headlight
LED
Position light
LED
Brake/tail light
LED
Speedometer
Digital
Tachometer
Digital
Fuel gauge
Digital
Hazard Function
Equipped*
Side stand engine cut-off switch
Equipped
Fuel consumption indicator
Equipped*
Gear position indicator
Equipped
Shift timing light
Equipped
VVA indicator
Equipped
Clock
Digital
VVA
Equipped
Y-Connect (Smartphone Bluetooth Connectivity)
Equipped
